Inline Production Metal Detector With Checkweigher,Checkweigher And Metal Detection In One Integrated Unit is mainly used in various food and pharmaceutical automatic assembly lines.
Inline Production Metal Detector With Checkweigher is mainly used in various food and pharmaceutical automatic assembly lines.On-line detection of metal substances and overweight or underweight after packaging. The materials are weighed on-line with high-precision dynamics, and the industrial computer performs precise grading.Checkweigher And Metal Detection In One Integrated Unit can directly replace manual weighing to improve production efficiency, improve accuracy and reduce labor, reduce labor intensity, and realize industrial automation.
Measuring method: electromagnetic induction / digital load cell
Accuracy: FE0.8mm SUS2.0mm
Selection accuracy: ±0.5g
Weighing range: 5 grams - 900 grams
Passing height: 110m
Pass width: 280mm
Packaging length: ≤300mm
Display graduation value: 0.1g 0.2g 0.5g 1g
Number of sorting segments: 3 segments
Sorting ability: 60 times/min
Conveyor belt speed: 10-45 m/min
Ground height: 735mm—800mm
Working temperature: 0-40℃
Weight: about 160kg
Dimensions: 1900mm×700mm×1120mm (L×W×H)
For reference only,please consult for details!
Contact us to recommend a product that is suitable for you !
1. It can be used to detect iron, copper, aluminum, and stainless steel mixed in non-metal products, and the iron and non-ferrous signals can be digitally displayed;
2. With the design of belt deviation correction, it is not easy to deviate during long-term operation.
3. Single and double coil detection can be used alone or together, with Chinese and English menus.
4. Adopt digital DSP programming design, LCD screen plus membrane switch touch control panel
5. It can automatically set and learn to obtain applicable detection performance, and can store and memorize 100 kinds of products.
6. With product effect automatic learning function, product effect filtering, small pieces of aluminum foil packaging can still detect stainless steel and non-ferrous metal copper test pieces.
7. The frame of the whole machine adopts stainless steel material laser cutting welding and wire drawing process, food white PVC or PU belt, 304 stainless steel pipe or non-metallic roller are optional
8. It has anti-seismic ability, and it is not easy to cause false alarms due to collision and knocking on the machine.
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
About the price
The price is based on the customer service quotation as the real price!
Seven-day replacement, one-year warranty, lifetime maintenance!
About the certificate
Each product will be equipped with a certificate of conformity before shipment, please rest assured to buy!
The delivery cycle is within 3-5 days after the order is placed. If there is stock, it will be sent out in a short time. The customer needs to customize it. The specific delivery time will be notified to you by the customer service track!
If the customer's product fails, we will provide you with a specific solution.
Please let us know the follow packing details when you need,so that we can check if this model is suitable for your case.Thank you in advance.
●Bag Width, Bag Length.
●Packing film material.
